DBW Open Rate Damping

DBW Open Rate Damping

DBW Open Rate Damping Table



This table sets The damping level applied to the electronic throttle when opening. This is used to soften the feel of the throttle to make it less sensitive to sudden movements, with higher numbers giving more dampening. To disable this set to zero. The maximum dampening available is 10.
