When enabled, allows control of reverse vehicle lights.

NOTE: This output requires some form of input or Gear Detection in order for the VCU to determine when to enable. This can be a wired AVI Input, a CAN based input, or Transmission control CAN input. Reverse switch must be enabled under the "Transmission" navigation node.
